Downside cut for PCB with tall components near cutting line
Features
- Max. PCB size 300mm × 400mm can be cut
- PCB is fixed in place by the conveyance unit holding down PCB from above
- Downside cut method can be adapted to PCB that can’t be cut from above
- This method can cut PCB with components mounted over across 2 pieces of its individuals
- Dust is well collected by local dust vacuum from below
- Its small dust collector generates about 65dB(A) and saves working space
- Program teaching is done by just reading CAD data (DXF file) and clicking on PC
- Jig bit sensors automatically read and open an appropriate program out of 31
- Component-mounted PCB can be cut safely and with little stress on it
[Standard equipment]
- PCB detection sensor
- PCB floating sensor
- Router bit broken/fallen sensor
